Kyocera PTGNR2525M-16 External Turning Toolholder – THC00410

The Kyocera PTGNR2525M-16 is a high-performance external turning toolholder designed for precision turning, profiling, and facing operations in CNC and manual machining environments. Manufactured with a rigid 25mm x 25mm...
$124.00
$0.00
$124.00
(-0%)
SKU: PTGNR2525M-16
Availability: In Stock
Subtotal: $124.00
KYOCERA ASIA PACIFIC PTE LTD TOOL HOLDERS Kyocera PTGNR2525M-16 External Turning Toolholder – THC00410

Kyocera PTGNR2525M-16 External Turning Toolholder – THC00410

$0.00 $124.00

Kyocera PTGNR2525M-16 External Turning Toolholder – THC00410

$0.00 $124.00

The Kyocera PTGNR2525M-16 is a high-performance external turning toolholder designed for precision turning, profiling, and facing operations in CNC and manual machining environments. Manufactured with a rigid 25mm x 25mm shank, this holder delivers excellent stability, reduced vibration, and consistent machining accuracy during medium to heavy-duty cutting applications.

Designed for use with TNMG style inserts size 16, the PTGNR2525M-16 features a right-hand cutting configuration and strong insert clamping system for reliable insert retention and smooth chip evacuation. Its robust construction and precision geometry make it ideal for machining steel, stainless steel, cast iron, and general engineering materials.

Key Features & Benefits

  • Suitable for external turning, profiling, and facing operations
  • Compatible with TNMG 16 inserts
  • Rigid 25mm square shank improves machining stability
  • Right-hand cutting design for standard turning applications
  • Strong insert clamping system for secure insert positioning
  • Excellent vibration resistance for improved surface finish
  • Ideal for CNC lathes and manual machining
  • Suitable for steel, stainless steel, and cast iron machining

Technical Specifications

  • Part Number: PTGNR2525M-16
  • Item Number: THC00410
  • Product Type: External Turning Toolholder
  • Holder Style: PTGNR
  • Cutting Direction: Right Hand
  • Insert Type: TNMG
  • Insert Size: 16
  • Shank Width (B): 25 mm
  • Shank Height (H): 25 mm
  • Total Length (OAL): 150 mm
  • Head Length (LH): 24 mm
  • Cutting Edge Angle: 91°
  • Corner Radius: 0.8 mm
  • Insert Thickness: 4.76 mm
  • Internal Coolant: No
  • Brand: Kyocera

Kyocera turning toolholders are engineered for precision machining performance, combining durability, rigidity, and reliable insert clamping to support efficient metal cutting across a wide range of industrial applications.
