Somta Series 134 – 9/32″ HSS Extra Length Straight Shank Drill

Somta Series 134 – 9/32″ HSS Extra Length Straight Shank Drill (Blue Finish) | 1340714 The SOMTA 1340714 is a 9/32″ High-Speed Steel Extra Length Straight Shank Drill engineered for...
$83.00
$0.00
$83.00
(-0%)
Vendor: SOMTA
SKU: 1340714
Availability: In Stock
Subtotal: $83.00
Somta Series 134 – 9/32″ HSS Extra Length Straight Shank Drill

Somta Series 134 – 9/32″ HSS Extra Length Straight Shank Drill

$0.00 $83.00

Somta Series 134 – 9/32″ HSS Extra Length Straight Shank Drill

$0.00 $83.00

Somta Series 134 – 9/32″ HSS Extra Length Straight Shank Drill (Blue Finish) | 1340714

The SOMTA 1340714 is a 9/32″ High-Speed Steel Extra Length Straight Shank Drill engineered for deep-hole drilling applications requiring extended reach and consistent precision. Manufactured to ISO 3292 / DIN 1869 standards, this drill offers excellent performance on steels, cast irons, and non-ferrous materials. Its rigid HSS construction and precision-ground flutes deliver stable cutting action, smooth chip evacuation, and excellent hole quality.

The blue-oxide finish improves lubrication and reduces friction during drilling, enhancing wear resistance and extending tool life. Designed for machinists and fabricators who demand precision and durability in extended-reach operations.

Key Features & Benefits

  • High-Speed Steel (HSS): Exceptional strength, edge retention, and heat resistance for extended use.
  • Extra Length Design: Provides deep-reach capability for holes beyond jobber-length drills.
  • Type N Helix (30°): General-purpose flute geometry suitable for most materials.
  • Blue Oxide Finish: Enhances lubrication, reduces friction, and resists built-up edge formation.
  • Straight Shank: Ensures secure chuck holding and improved concentricity.

Technical Specifications

  • Part No: 1340714
  • Series: 134 (HSS Extra Length Straight Shank Drills – Inch Series)
  • Tool Type: Extra Length HSS Drill – Type N
  • Cutting Diameter (d): 9/32″ (7.14 mm)
  • Flute Length (l₁): 8"
  • Overall Length (l): 250 mm
  • Shank Type: Straight Shank
  • Helix Type: Type N (30° Right-Hand Spiral)
  • Point Angle: 118° Standard Point
  • Material: High-Speed Steel (HSS)
  • Finish: Blue Oxide
  • Applications: Ideal for deep drilling in steel, cast iron, and non-ferrous materials where extended reach is required.

Why Choose SOMTA Cutting Tools?

  • Precision Manufacture: Built to ISO/DIN standards for dimensional accuracy and repeatability.
  • Long-Lasting Durability: Hardened HSS core maintains edge stability under continuous use.
  • Superior Chip Evacuation: Precision-ground flutes minimize heat and friction build-up.
  • Trusted SOMTA Quality: Decades of manufacturing excellence since 1954.

The SOMTA 1340714 delivers deep-drilling accuracy, wear resistance, and consistent performance for industrial machining tasks. Available through Twin Eagle Imports — your trusted partner for premium industrial tooling solutions.
