Somta Series 510 - HSSE-V Spiral Flute Tap Metric M5 x 0.8 (Standard)

Optimized for High-Performance Blind Hole Tapping The Somta Series 510 HSSE-V Spiral Flute Tap Metric M5 x 0.8 is a high-performance machine tap specifically designed for blind hole applications. Featuring...
$26.00
$26.00
(-0%)
Vendor: SOMTA
SKU: 5100500
Availability: In Stock
Subtotal: $26.00
Twin Eagles  SOMTA - HSSE-V SPIRAL FLUTE TAP METRIC 5.0 X 0.8 (STANDARD)

Somta Series 510 - HSSE-V Spiral Flute Tap Metric M5 x 0.8 (Standard)

$26.00

Somta Series 510 - HSSE-V Spiral Flute Tap Metric M5 x 0.8 (Standard)

$26.00

Optimized for High-Performance Blind Hole Tapping

The Somta Series 510 HSSE-V Spiral Flute Tap Metric M5 x 0.8 is a high-performance machine tap specifically designed for blind hole applications. Featuring a 15° right-hand helix, this tap efficiently lifts swarf upward, ensuring clean and precise threading in CNC and conventional machines.

Key Features & Benefits
Ideal for Blind Holes – Spiral flute design effectively lifts chips out of the hole, preventing clogging and ensuring smooth operation.
HSSE-V3 High-Speed Steel – Exceptional wear resistance and extended tool life for reliable performance in demanding applications.
60° Thread Flank Angle – Ensures strong, accurate, and consistent thread formation.
15° Right-Hand Helix – Optimized for effective chip removal in blind hole applications.
Right-Hand Cutting – Designed for standard metric (M) threading applications.
ISO 529 Standard – Manufactured to industry-grade specifications for consistency and reliability.
Versatile General-Purpose Use – Suitable for a wide range of materials and machining operations.

Technical Specifications
🔹 Thread Size: M5 x 0.8
🔹 Thread Standard: Metric (M)
🔹 Thread Tolerance Class: ISO 2 (6H)
🔹 Flank Angle: 60°
🔹 Helix Angle: 15° Right-Hand
🔹 Tap Type: Spiral Flute Short Machine Tap
🔹 Cutting Direction: Right-Hand
🔹 Application: General-Purpose Blind Hole Tapping
🔹 Shank Standard: ISO 529
🔹 Material: HSSE-V3 (High-Speed Steel)
🔹 Hole Type: Blind Hole

Why Choose the Somta Series 510 M5 x 0.8 Spiral Flute Tap?
Optimized for Blind Hole Applications – Spiral flute design ensures effective chip evacuation for smooth and accurate threading.
Durable HSSE-V3 Material – High-speed steel with enhanced wear resistance for longer tool life.
Reliable & Consistent Performance – ISO 2 (6H) tolerance ensures precise metric threads every time.
Efficient Cutting Action – 15° right-hand helix provides smooth cutting and reduces friction.

Achieve exceptional accuracy and efficiency with the Somta Series 510 HSSE-V Spiral Flute Tap Metric M5 x 0.8 – the ideal tool for professional blind hole tapping applications.
